Structure configuration:

1. Automatic control, the single-person and single-air shower system adopts PLC intelligent control method, and the LED display on the control panel can correctly display the running status of the air shower, the interlocking state of the double doors, the progress of the air shower cycle and the delayed door opening. state. It is also equipped with a photoelectric sensor, a one-way channel air shower room, entering from a non-clean area, after the door is closed, the infrared ray senses people and blows the shower, after blowing the shower, the door is locked, and you can only walk out of the air shower room;

2. Single-person single-air shower room main board soft key touch-type time relay, LED display and setting blowing time, the range is adjustable from 10-99s, and the blowing time can be adjusted according to the difference of the external environment of the air shower;

3. Modular structure, single-person single-air shower box adopts modular design scheme;

4. High performance, high sealing, using imported electronic components, stable and reliable operation performance, advanced noise reduction and mute device system and EVA sealing material, high sealing performance.

Use Note:

Ultraviolet germicidal lamps are actually a low-pressure mercury lamp. The low-pressure mercury lamp is excited by a lower mercury vapor pressure to emit ultraviolet light. There are two main emission lines: one is 253.7nm wavelength; the other is 185nm wavelength, both of which are invisible to the naked eye. Because ultraviolet rays will kill cells, be careful not to directly irradiate human skin, especially eyes, when ultraviolet rays are sterilized. Do not look directly at the lamp tube when the ultraviolet germicidal lamp is on. Because short-wave ultraviolet rays do not pass through ordinary glass, wearing glasses can avoid it. Eye damage. Infrared automatic induction air shower room means that after the infrared sensor is cut off from the light sensor at the other end, the entire intelligent circuit board system detects that people stand in the induction area and automatically starts all devices, so as to achieve automatic showering. Therefore, it is not advisable to turn on the UV germicidal lamp for a long time when using the UV germicidal lamp in the air shower. It is set to switch on the UV germicidal lamp to protect the operator and reduce human injury.
